Mighty Mite Strat Neck Compound – Maple/Rosewood Locking Nut – R2

Description

Strat® style replacement neck features a compound radius, rosewood fingerboard fitted with 22 jumbo frets; and nut is cut for R2 Locking nut (nut not included).  If installing vintage tuners; you may be required to install 10 mm adapter bushings.  Mighty Mite / FU-Tone does not supply these bushings.

WOODS & MATERIALS
Fretboard Material Rosewood

Neck Material Maple

Skunk Stripe Rosewood

Finish Satin, Thin Polyurethane Oil Based

SIZE & SHAPE
Neck Profile Shape C Shape

Orientation Right-hand

Scale Length 25 ½”

Radius 9.5 at nut, 12” compound at 22^nd fret

Heel Size approximately: 2 11/64” wide by 3” high and 5/8” deep

FRETS & MORE
Number of Frets 22

Fret Size Jumbo – 2.9mm – Nickel

Inlays Pearloid Dots

Side Dots White

Truss Rod Single-adjust at headstock – 4mm wrench not included

Tuner Hole Size 10mm 6-in-line Modern Tuners

LIMITED WARRANTY
Mighty Mite^® is not affiliated with Fender^® and no Fender^® warranty applies.

To validate the limited warranty, the original purchaser must complete a Product Registration Form and send within 10 days following the original date of receiving your neck.  The warranty is not transferable.For more information regarding the limited warranty, return and exchange policies go to www.MightyMite.com Resources/Warranty.

 CONDITIONS OF USE

This replacement neck is for Fender^® or Squier^® by Fender^® guitar only.  This neck is licensed as a replacement neck and may not be used to assemble Non-Fender^® Guitars.  This neck is licensed to Mighty Mite^® by Fender^® Musical Instruments under a quality control trademark license.
